Lattice LC4256V-75TN176C復雜可編程邏輯器件(CPLD)
發布時間：2024-09-11 09:25:56 瀏覽：1067
Lattice半導體公司推出的LC4256V-75TN176C是一款高性能的復雜可編程邏輯器件(CPLD)，屬于ispMACH
4000V/B家族，符合RoHS標準，確保環境友好。該產品設計精良，旨在滿足現代工業控制和通信系統對性能和可靠性的高要求。
系統屬性
該CPLD包含16個邏輯模塊，提供4個全局時鐘和2個I/O Bank。其程序存儲類型為EEPROM，內置防振器，確保數據的安全性和穩定性。
軟/硬件規格
LC4256V-75TN176C擁有256個論壇宏DB包含數，80個宏單元和576個寄存器。最大用戶I/O數達到128，支持在線系統編程和可重編程性。其最大頻率為168
MHz，最大時鐘到輸出延遲為4.5 ns，最大地傳送延遲為7.5 ns，速度等級為75，且受時間抖動控制。
電氣參數
該產品支持的最大工作電源電壓為3.6 V，最小為3 V，額定工作電源電壓為3.3 V。靜態功耗電值為5 mA，最大工作重點電流為12.5
mA。
環境/機械特性
LC4256V-75TN176C的最低工作溫度為0℃，最高工作溫度為90℃，適應多種環境條件。
包裝信息
該CPLD采用商業供應鏈，封裝形式為托盤，商名為ispMACH 4000。安裝方式為表面焊裝，包裝尺寸為寬度14 mm，高度2.4 mm，長度24
mm。引線數目為176，PCB散熱采用QFP塑，封裝驗證為TQFP驗證，引腳數為176，引線形狀為扁平型。
LC4256V-75TN176C
CPLD以其卓越的性能和可靠性，成為工業控制和通信系統等領域的理想選擇。其靈活的編程能力和穩定的運行特性，確保了系統的高效運行和長期穩定性。
相關型號：
| Device | Part Number | Macrocells | Voltage | tpD | Package | Pin/Ball Count | /O | Grade |
| LC4256V | LC4256V-3FT256AC | 256 | 3.3 | 3 | ftBGA | 256 | 128 | C |
| LC4256V-5FT256AC | 256 | 3.3 | 5 | ftBGA | 256 | 128 | C |
| LC4256V-75FT256AC | 256 | 3.3 | 7.5 | ftBGA | 256 | 128 | C |
| LC4256W-3FT256BC | 256 | 3.3 | 3 | ftBGA | 256 | 160 | C |
| LC4256V-5FT256BC | 256 | 3.3 | 5 | ftBGA | 256 | 160 | C |
| LC4256V-75FT256BC | 256 | 3.3 | 7.5 | ftBGA | 256 | 160 | C |
| LC4256V-3F256AC1 | 256 | 3.3 | 3 | fpBGA | 256 | 128 | C |
| LC4256V-5F256AC | 256 | 3.3 | 5 | fpBGA | 256 | 128 | C |
| LC4256V-75F256AC | 256 | 3.3 | 7.5 | fpBGA | 256 | 128 | C |
| LC4256W-3F256BC | 256 | 3.3 | 3 | fpBGA | 256 | 160 | C |
| LC4256W-5F256BC | 256 | 3.3 | 5 | fpBGA | 256 | 160 | C |
| LC4256V-75F256BC1 | 256 | 3.3 | 7.5 | fpBGA | 256 | 160 | C |
| LC4256V-3T176C | 256 | 3.3 | 3 | TQFP | 176 | 128 | C |
| LC4256V-5T176C | 256 | 3.3 | 5 | TQFP | 176 | 128 | C |
| LC4256V-75T176C | 256 | 3.3 | 7.5 | TQFP | 176 | 128 | C |
| LC4256W-3T144C | 256 | 3.3 | 3 | TQFP | 144 | 96 | C |
| LC4256V-5T144C | 256 | 3.3 | 5 | TQFP | 144 | 96 | C |
| LC4256V-75T144C | 256 | 3.3 | 7.5 | TQFP | 144 | 96 | C |
| LC4256V-3T100C | 256 | 3.3 | 3 | TQFP | 100 | 64 | C |
| LC4256V-5T100C | 256 | 3.3 | 5 | TQFP | 100 | 64 | C |
| LC4256V-75T100C | 256 | 3.3 | 7.5 | TQFP | 100 | 64 | C |
| LC4256V | LC4256V-5FT256AI | 256 | 3.3 | 5 | ftBGA | 256 | 128 | I |
| LC4256V-75FT256Al | 256 | 3.3 | 7.5 | ftBGA | 256 | 128 | I |
| LC4256Y-10FT256Al | 256 | 3.3 | 10 | ftBGA | 256 | 128 | I |
| LC4256V-5FT256B | 256 | 3.3 | 5 | ftBGA | 256 | 160 | I |
| LC4256V-75FT256BI | 256 | 3.3 | 7.5 | ftBGA | 256 | 160 | I |
| LC4256V-10FT256BI | 256 | 3.3 | 10 | ftBGA | 256 | 160 | I |
| LC4256W-5F256Al | 256 | 3.3 | 5 | fpBGA | 256 | 128 | I |
| LC4256V-75F256AI | 256 | 3.3 | 7.5 | fpBGA | 256 | 128 | I |
| LC4256W-10F256AI | 256 | 3.3 | 10 | fpBGA | 256 | 128 | I |
| LC4256W-5F256BI | 256 | 3.3 | 5 | fpBGA | 256 | 160 | I |
| LC4256V-75F256BI1 | 256 | 3.3 | 7.5 | fpBGA | 256 | 160 | I |
| LC4256V-10F256BI | 256 | 3.3 | 10 | fpBGA | 256 | 160 | I |
| LC4256V-5T176I | 256 | 3.3 | 5 | TQFP | 176 | 128 | I |
| LC4256V-75T176I | 256 | 3.3 | 7.5 | TQFP | 176 | 128 | I |
| LC4256Y-10T176I | 256 | 3.3 | 10 | TQFP | 176 | 128 | I |
| LC4256W-5T1441 | 256 | 3.3 | 5 | TQFP | 144 | 96 | I |
| LC4256Y-75T144I | 256 | 3.3 | 7.5 | TQFP | 144 | 96 | I |
| LC4256V-10T144I | 256 | 3.3 | 10 | TQFP | 144 | 96 | I |
| LC4256W-5T100I | 256 | 3.3 | 5 | TQFP | 100 | 64 | I |
| LC42568-75T100I | 256 | 3.3 | 7.5 | TQFP | 100 | 64 | I |
| LC4256V-10T100I | 256 | 3.3 | 10 | TQFP | 100 | 64 | I |
| LC4256V | LC4256W-75T176E | 256 | 3.3 | 7.5 | TQFP | 176 | 128 | E |
| LC4256W-75T144E | 256 | 3.3 | 7.5 | TQFP | 144 | 96 | E |
| LC4256V-75T100E | 256 | 3.3 | 7.5 | TQFP | 100 | 64 | E |
| LC4256V | C4256V-3FTN256AC | 256 | 3.3 | 3 | Lead-free ftBGA | 256 | 128 | C |
| LC4256V-5FTN256AC | 256 | 3.3 | 5 | Lead-free ftBGA | 256 | 128 | C |
| LC4256V-75FTN256AC | 256 | 3.3 | 7.5 | Lead-free ftBGA | 256 | 128 | C |
| LC4256V-3FTN256BC | 256 | 3.3 | 3 | Lead-free ftBGA | 256 | 160 | C |
| LC4256V-5FTN256BC | 256 | 3.3 | 5 | Lead-free ftBGA | 256 | 160 | C |
| LC4256V-75FTN256BC | 256 | 3.3 | 7.5 | Lead-free ftBGA | 256 | 160 | C |
| LC4256V-3FN256AC | 256 | 3.3 | 3 | Lead-free fpBGA | 256 | 128 | C |
| LC4256V-5FN256AC | 256 | 3.3 | 5 | Lead-free fpBGA | 256 | 128 | C |
| LC4256V-75FN256AC1 | 256 | 3.3 | 7.5 | Lead-free fpBGA | 256 | 128 | C |
| LC4256V-3FN256BC | 256 | 3.3 | 3 | Lead-free fpBGA | 256 | 160 | C |
| LC4256V-5FN256BC1 | 256 | 3.3 | 5 | Lead-free fpBGA | 256 | 160 | C |
| LC4256V-75FN256BC | 256 | 3.3 | 7.5 | Lead-free fpBGA | 256 | 160 | C |
| LC4256V-3TN176C | 256 | 3.3 | 3 | Lead-free TOFP | 176 | 128 | C |
| LC4256V-5TN176C | 256 | 3.3 | 5 | Lead-free TQFP | 176 | 128 | C |
| LC4256V-75TN176C | 256 | 3.3 | 7.5 | Lead-free TOFP | 176 | 128 | C |
| LC4256V-3TN144C | 256 | 3.3 | 3 | Lead-free TQFP | 144 | 96 | C |
| LC4256V-5TN144C | 256 | 3.3 | 5 | Lead-free TQFP | 144 | 96 | C |
| LC4256V-75TN144C | 256 | 3.3 | 7.5 | Lead-free TQFP | 144 | 96 | C |
| LC4256V-3TN100C | 256 | 3.3 | 3 | Lead-free TQFP | 100 | 64 | C |
| LC4256V-5TN100C | 256 | 3.3 | 5 | Lead-free TQFP | 100 | 64 | C |
| LC4256V-75TN100C | 256 | 3.3 | 7.5 | Lead-free TQFP | 100 | 64 | C |
